Nissan Dashboard Warning Lights and Meanings (FULL list, FREE Download)

This light comes on when the ignition switch is placed in the ON position. It turns off after the engine is started.
This light illuminates when the AEB with Pedestrian Detection system is set to OFF in the vehicle information display.
If the light illuminates when the AEB with Pedestrian Detection system is on, it may indicate that the system is unavailable

When the ignition is in the ON position, the master warning light illuminates if any of the following are displayed on the vehicle information display.
● No key warning
● Low windshield-washer fluid warning
● Door open warning (when stopped)
● Trunk open warning
● Loose fuel cap
● Low tire pressure warning
● AWD warning
If the master warning light illuminates and the message(s) are not visible on the vehicle information display, use the buttons located on the steering wheel to navigate the vehicle information display until the “Warnings” screen is displayed.

This indicator light will blink when the Vehicle Dynamic Control (VDC) system is operating, thus alerting the driver to the fact that the road surface is slippery and the vehicle is nearing its traction limits. You may feel or hear the system working; this is normal.
The light will blink for a few seconds after the VDC system stops limiting the wheel spin. The indicator light also comes on when you place the ignition switch in the ON position. The light will turn off after approximately 2 seconds if the system is operational. If the light does not come on have the system checked. It is recommended that you visit a NISSAN dealer for this service.

MIL on steady – An emission control system malfunction has been detected.
Check the fuel-filler cap if the Loose Fuel Cap warning appears in the vehicle information display. If the fuel-filler cap is loose or missing, tighten or install the cap and continue to drive the vehicle. The light should turn off after a few driving trips. If the light does not turn off after a few driving trips, have the vehicle inspected. It is recommended that you visit a NISSAN dealer for this service. You do not need to have your vehicle towed to the dealer.
MIL blinking – An engine misfire has been detected which may damage the emission control system. To reduce or avoid emission control system damage:
● Do not drive at speeds above 45 mph (72 km/h).
● Avoid hard acceleration or deceleration.
● Avoid steep uphill grades.
● If possible, reduce the amount of cargo being hauled or towed.
The MIL may stop blinking and come on steady. Have the vehicle inspected. It is recommended that you visit a NISSAN dealer for this service. You do not need to have your vehicle towed to the dealer.

This indicator light comes on when the VDC is turned off in the vehicle information display. Turn the VDC on using the vehicle information display, or by restarting the engine.
The VDC light also comes on when the ignition switch is placed in the ON position. The light will turn off after a period of time if the system is operational. If the light stays on or comes on along with the indicator light while you are driving, have the VDC system checked. It is recommended that you visit a NISSAN dealer for this service.

When the ignition switch is placed in the ON position, the ABS warning light illuminates and then turns off. This indicates the ABS is operational.
If the ABS warning light illuminates while the engine is running or while driving, it may indicate the ABS is not functioning properly. Have the system checked. It is recommended that you visit a NISSAN dealer for this service.
If an ABS malfunction occurs, the anti-lock function is turned off. The brake system then operates normally but without antilock assistance.

When the ignition switch is placed in the ON position, this light comes on briefly and then turns off.
The light comes on when the hill descent control system is activated.
● If the hill descent control switch is on and the indicator light blinks, the system is not engaged.
● If the indicator light does not come on when the hill descent switch is on, the system may not be functioning properly. Have the system checked. It is recommended that you visit a NISSAN dealer for this service.

If the warning light illuminates, it may indicate the electronic parking brake system is not functioning properly. Have the system checked. It is recommended that you visit a NISSAN dealer for this service.

Low tire pressure warning
If the vehicle is being driven with low tire pressure, the warning light will illuminate. A “Tire Pressure Low – Add Air” warning also appears in the vehicle information display.
When the low tire pressure warning light illuminates, you should stop and adjust the tire pressure of all four tires to the recommended COLD tire pressure shown on the Tire and Loading Information label located in the driver’s door opening. The low tire pressure warning light does not automatically turn off when the tire pressure is adjusted. After the tire is inflated to the recommended pressure, the vehicle must be driven at speeds above 16 mph (25 km/h) to activate the TPMS and turn off the low tire pressure warning light. Use a tire pressure gauge to check the tire pressure.
The “Tire Pressure Low – Add Air” warning appears each time the ignition switch is placed in the ON position as long as the low tire pressure warning light remains illuminated.
TPMS malfunction
If the TPMS is not functioning properly, the low tire pressure warning light will flash for approximately 1 minute when the ignition switch is placed in the ON position. The light will remain on after 1 minute. Have the system checked. It is recommended that you visit a dealer for this service. The “Tire Pressure Low — Add Air” warning does not appear if the low tire pressure warning light illuminates to indicate a TPMS malfunction.

This light comes on when the ignition switch is placed in the ON position. It turns off after the engine is started.
This light illuminates when the RAB system is turned off in the vehicle information display.
If the light illuminates when the RAB system is on, it may indicate that the system is unavailable.

This light comes on when the ignition switch is placed in the ON position. It turns off after the engine is started.
This light illuminates when the RAB system is turned off in the vehicle information display.
If the light illuminates when the RAB system is on, it may indicate that the system is unavailable.

The overdrive off indicator light illuminates when the overdrive off mode is selected.

When the ignition switch is placed in the ON position, the ABS warning light illuminates and then turns off. This indicates the ABS is operational.
If the ABS warning light illuminates while the engine is running or while driving, it may indicate the ABS is not functioning properly. Have the system checked. It is recommended that you visit a NISSAN dealer for this service.
If an ABS malfunction occurs, the anti-lock function is turned off. The brake system then operates normally but without antilock assistance.

When the ignition switch is in the ON position, the AEB system OFF warning light illuminates. After starting the engine, the warning light turns off.
This light illuminates when the AEB with Pedestrian Detection system is set to OFF on the vehicle information display.
If the light illuminates or flashes when the AEB with the Pedestrian Detection system is ON, it may indicate that the system is unavailable

This indicator light will blink when the Vehicle Dynamic Control (VDC) system is operating, thus alerting the driver to the fact that the road surface is slippery and the vehicle is nearing its traction limits. You may feel or hear the system working; this is normal.
The light will blink for a few seconds after the VDC system stops limiting the wheel spin. The indicator light also comes on when you place the ignition switch in the ON position. The light will turn off after approximately 2 seconds if the system is operational. If the light does not come on have the system checked. It is recommended that you visit a NISSAN dealer for this service.

This light illuminates if there is a malfunction in the following systems.
● Traction motor and inverter system
● Charge port or on-board charger
● Li-ion battery system
● Cooling system
● Shift control system
● Emergency shut-off system is activated.
Have the system checked. It is recommended that you visit a NISSAN-certified LEAF dealer for this service.

MIL on steady – An emission control system malfunction has been detected.
Check the fuel-filler cap if the Loose Fuel Cap warning appears in the vehicle information display. If the fuel-filler cap is loose or missing, tighten or install the cap and continue to drive the vehicle. The light should turn off after a few driving trips. If the light does not turn off after a few driving trips, have the vehicle inspected. It is recommended that you visit a NISSAN dealer for this service. You do not need to have your vehicle towed to the dealer.
MIL blinking – An engine misfire has been detected which may damage the emission control system. To reduce or avoid emission control system damage:
● Do not drive at speeds above 45 mph (72 km/h).
● Avoid hard acceleration or deceleration.
● Avoid steep uphill grades.
● If possible, reduce the amount of cargo being hauled or towed.
The MIL may stop blinking and come on steady. Have the vehicle inspected. It is recommended that you visit a NISSAN dealer for this service. You do not need to have your vehicle towed to the dealer.

When the ignition switch is placed in the ON position, the power steering warning light illuminates. After starting the engine, the power steering warning light turns off. This indicates the power steering is operational.
If the power steering warning light illuminates while the engine is running, it may indicate the power steering is not functioning properly and may need servicing. Have the power steering checked. It is recommended that you visit a NISSAN dealer for this service.
When the power steering warning light illuminates with the engine running, there will be no power assist for the steering, but you will still have control of the vehicle. At this time, greater steering effort is required to operate the steering wheel, especially in sharp turns and at low speeds.

This warning appears when the fuel level in the fuel tank is getting low. Refuel as soon as it is convenient, preferably before the fuel gauge reaches 0 (Empty). There will be a small reserve of fuel in the tank when the fuel gauge needle reaches 0 (Empty).

This warning appears when the windshield washer fluid is at a low level. Add windshield washer fluid as necessary

When the ignition switch is in the “ON” position, the All-Wheel Drive (AWD) AUTO indicator light illuminates.
If the master warning light comes on during operation, have your vehicle checked. It is recommended that you visit a NISSAN dealer for this service.

If the warning light illuminates, it may indicate the electronic parking brake system is not functioning properly. Have the system checked. It is recommended that you visit a NISSAN dealer for this service.

The front passenger air bag status light will be lit and the passenger front airbag will be off depending on how the front passenger seat is being used.

The warning light comes on when the ignition switch is placed in the ON position. It turns off soon after the engine is started.
If the 4WD system malfunctions, or the diameter of the front and the rear wheels are different, the warning light will either remain illuminated or blink.

This light appears when the shift lever is in the P (Park) position. This light means that the engine will start by pushing the ignition switch with the brake pedal depressed. You can start the engine directly in any position.

This light comes on if there is a malfunction in the Approaching Vehicle Sound for Pedestrians (VSP) system.
If the VSP system OFF warning light illuminates while the power switch is in the ON position, or in the READY to drive position, it may indicate the VSP system is not functioning properly. Have the system checked. It is recommended that you visit a NISSAN-certified LEAF dealer for this service.

When the power limitation indicator light is illuminated, the power provided to the traction motor is reduced. Therefore the vehicle is not as responsive when the accelerator is depressed while the power limitation light is illuminated.
This light illuminates in the following conditions.
● If the low battery charge indicator is illuminated, charge the Li-ion battery as soon as possible.
● If this indicator illuminates because the Li-ion battery is cold due to low outside temperatures, move the vehicle to a warmer location. The Li-ion battery temperature may be increased by charging the Li-ion battery.
● If the light illuminates when the EV system becomes hot due to continuous hill climbing, either continue driving at a slower safe speed or stop the vehicle in a safe location.
● The indicator illuminates when a part of the EV system has malfunctioned. If the indicator illuminates in a situation other than those described above, or if it does not turn off, there may be a system malfunction. Have the system checked. It is recommended that you visit a NISSAN-certified LEAF dealer for this service.

This light illuminates when there is an error with the system.

This light illuminates when the soft top is being operated or it is stopped before reaching a full open/close state. When the top is fully opened or closed, the light will turn off.
The light blinks while the soft top is not fully opened or closed under the following conditions:
● When the vehicle is driven.
● When the shift lever is in the R (Reverse) position.
Be sure to fully open or close the soft top when driving the vehicle.
The soft top can be moved with the soft top operating switch only under all of the following conditions:
● When the vehicle is stopped.
● When the ignition switch is ON.
● When the trunk is closed.
● When the shift lever is in a position other than the R (Reverse) position.

The front passenger air bag status light will be lit and the passenger front airbag will be off depending on how the front passenger seat is being used.

When the ignition switch is placed in the ON position, the light comes on for 2 seconds.
If the light comes on at any other time, it may indicate the transmission is not functioning properly. It is recommended you visit a NISSAN dealer to check and repair the transmission.

When the ignition switch is in the ON position, the electric power steering warning light illuminates. After starting the engine, the electric power steering warning light turns off. This indicates the electric power steering system is operational.
If the electric power steering warning light illuminates while the engine is running, it may indicate the electric power steering system is not functioning properly and may need servicing. Have the electric power steering system checked by a NISSAN dealer.
When the electric power steering warning light illuminates with the engine running, the power assist to the steering will cease operation but you will still have control of the vehicle. At this time, greater steering efforts are required to operate the steering wheel, especially in sharp turns and at low speeds.

When the ignition switch is placed in the ON position, the light comes on for 2 seconds.

This light comes on when the electronic locking rear differential (E-Lock) system clutch is fully engaged.
The indicator light flashes when the system is first turned on. When the system fully engages, the light remains on. If the switch is on and the indicator light continues to flash, the system is not engaged.

This indicator appears if the outside temperature is below 37°F (3°C). The temperature can be changed to display in Fahrenheit or Celsius.

This indicator appears when the Intelligent Key battery is running out of power. If this indicator appears, replace the battery with a new one.

This indicator appears when the BSW system is engaged.

This indicator appears when the LDW system is engaged.

The Loose Fuel Cap warning message will be displayed in the vehicle information display when the fuel-filler cap is not tightened correctly after the vehicle has been refueled. It may take a few driving trips for the message to be displayed. To turn off the warning, perform the following:
1. Remove and install the fuel-filler cap as soon as possible.
2. Tighten the fuel-filler cap until it clicks.
3. Press the OK button on the steering wheel for about 1 second to turn off the Loose Fuel Cap warning after tightening the fuel-filler cap.

When the ignition switch is placed in the ON position, the indicator light shows the shift selector position.

When the ignition switch is placed in the ON position, the indicator light shows the shift selector position.

When the ignition switch is in the “ON” position, the All-Wheel Drive (AWD) indicator light illuminates and then turns off.
When selecting AWD mode while the engine is running, the AWD indicator light illuminates.

After the ignition switch is placed in the ON position, this light comes on for about 2 seconds and then turns off.
This light illuminates or blinks as follows:
● The light blinks in yellow when the door is closed with the Intelligent Key left outside the vehicle and the ignition switch in the ACC or ON position. Make sure that the Intelligent Key is inside the vehicle.
● The light blinks in green when the Intelligent Key battery is running out of power. Replace the battery with a new one.
● The light illuminates in yellow when it warns of a malfunction with the Intelligent Key system.
If the warning light illuminates yellow while the engine is stopped, it may be impossible to start the engine.
If the light comes on while the engine is running, you can drive the vehicle. However, in these cases, contact a NISSAN dealer for repair as soon as possible.

This light comes on when the 4WD shift switch is set in the 4LO position with the ignition switch in the ON position. The transfer case may be damaged if you shift the switch while driving.
The indicator light may blink while shifting from one drive mode to the other.
The 4LO indicator light must stop blinking and remain illuminated or turn off before shifting the transmission into gear. If the shift lever is shifted from the N (Neutral) position to any other gear when the 4LO indicator light is blinking, the vehicle may move unexpectedly.
When you shift between 4H and 4LO, follow the instructions below: Stop the vehicle and move the shift lever to the N (Neutral) position with the brake pedal depressed, then depress and turn the 4WD shift switch to 4LO or 4H.
You cannot move the transfer 4WD shift switch between 4H and 4LO unless you stop the vehicle and move the shift lever to the N (Neutral) position with the brake pedal depressed.

Transmission system malfunction: The light blinks if a malfunction in the transmission system occurs. If the light blinks, certain gear positions may become unusable, so the vehicle may become undrivable. It is recommended you have the system inspected promptly by a GT-R-certified NISSAN dealer.
Transmission oil temperature high: The light illuminates if the transmission oil temperature becomes unusually high. If the light illuminates, avoid driving at high speed or at high engine speed until the light turns off. The light will turn off after a short period of time and the vehicle can then be driven normally. If the light illuminates frequently, it is recommended you contact a GT-R-certified NISSAN dealer.

When the ignition switch is in the ON position, the All-Wheel Drive (AWD) LOCK indicator light illuminates and then turns off.
When selecting AWD LOCK mode while the hybrid system is running, the AWD LOCK indicator light illuminates.

The light should turn off within 1 second after placing the ignition switch in the ON position.
While the engine is running, the 4WD shift indicator light will illuminate the position selected by the 4WD shift switch.
The 4WD shift indicator light may blink while shifting from one drive mode to the other.
