Honda P1297: Electrical Load Detector (ELD) Circuit Low Voltage
Is your scanner showing Honda P1297?
No worries. We'll show you what it means and how to deal with it.
Honda P1297: Electrical Load Detector (ELD) Circuit Low Voltage
OVERVIEWWhat Does The Honda P1297 Code Mean?
The ELD output voltage is 0.27 V or less for at least 5 seconds. The execution time is continuous and DTC P1298 is not active. NOTE: Before you troubleshoot, record all freeze data and any on-board snapshot.
What Are The Potential Causes Of The Honda P1297 Code?
- Poor connections or loose terminals at the ELD and the PCM
- “Short” circuit between the PCM and the ELD
- Faulty left side engine compartment wire harness
- Faulty ELD
- PCM may need to be updated with the latest software
- Faulty PCM
Recommended Parts
Below are some recommended auto parts to help you address the trouble code affecting your vehicle and get it running smoothly again:
Note: During the purchasing process, please check carefully whether the part you want to buy fits your car!
Reference Sources
- Honda DTC Codes for P1297 – Page 3.
- DTC Troubleshooting – MotoLogic, 2003 Honda Odyssey
