Chrysler B1D97: Steering Column Tilt Motor Control - Circuit Performance
Is your scanner showing Chrysler B1D97?
No worries. We'll show you what it means and how to deal with it.
Chrysler B1D97: Steering Column Tilt Motor Control - Circuit Performance
OVERVIEWWhat Does The Chrysler B1D97 Code Mean?
The Memory System is made up of the Memory Seat Module (MSMD), Memory Switch, Driver Seat Switch, Tilt/Tilt Switch, multiple Seat Motors which also each contain a hall-effect position sensor, and the Tilt and Telescope Steering Motors, both of which contain a hall-effect position sensor.
What Are The Potential Causes Of The Chrysler B1D97 Code?
- (P151) tilt steering up/down position sense circuit open or excessive resistance
- (g914) sensor ground circuit open or excessive resistance
- (p153) tilt steering motor up/down driver circuit shorted to voltage
- (p153) tilt steering motor up/down driver circuit shorted to ground
- (p153) tilt steering motor up/down driver circuit open or excessive resistance
- (p953) steering motor common circuit shorted to voltage
- (p953) steering motor common circuit shorted to ground
- (p953) steering motor common circuit open or excessive resistance
- Steering column tilt motor
- Memory seat module
Recommended Parts
Below are some recommended auto parts to help you address the trouble code affecting your vehicle and get it running smoothly again:
>>> WORKPRO 582-piece Crimp Terminals, Wire Connectors, Heat Shrink Tube, Electrical Repair Kit
>>> Chrysler Steering Column Tilt Motor
>>> Seat Memory Module - Mopar (5026619AG)
Note: During the purchasing process, please check carefully whether the part you want to buy fits your car!
