Chrysler B1660: Front Fog Lamp Control Circuit High

OVERVIEW
Severity
:
Medium
DIY Difficulty Level
:
Intermediate
Repair Cost
:
$130-$250
Can I Still Drive?
:
Yes (Short-term only)

What Does The Chrysler B1660 Code Mean?

The Totally Integrated Power Module (TIPM) receives a bus message requesting fog lamp illumination. When this bus message is received, the TIPM provides a voltage output through the front fog lamps relay driver circuit. The front fog lamps relay driver circuit connects to the Front Fog Lamps Relay, which when energized provides battery voltage to the Front Fog Lamps.

What Are The Potential Causes Of The Chrysler B1660 Code?

  • (L139) Front fog lamps relay driver circuit open
  • (L139) Front fog lamps relay driver circuit shorted to voltage
  • Front fog lamps relay
  • Totally integrated power module (TIPM)

Recommended Parts

Below are some recommended auto parts to help you address the trouble code affecting your vehicle and get it running smoothly again:

>>> WORKPRO 582-piece Crimp Terminals, Wire Connectors, Heat Shrink Tube, Electrical Repair Kit
>>> Dorman 599-917 Remanufactured Totally Integrated Power Module

Note: During the purchasing process, please check carefully whether the part you want to buy fits your car!

Reference Sources

Chrysler B1660, DTCDECODE.
